2025 第九届工业信息安全技能大赛-典型工业场景锦标赛 Misc Writeup

1

tshark -r 工业控制协议流量分析1.pcap -T fields -Y 'tcp' -e 'tcp.segment_data' > out.txt

1

tshark -r 工业控制协议流量分析1.pcap -T fields -Y 'len(tcp.segment_data) != 13' -e 'tcp.segment_data' > out.txt

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14

6e310000000901666c0304cdd0141e
0a400000000901030461677b399dde,e50e
187a00000009013437316603045f10,8121
792d000000096433322d010304bc9a,b5b0
224600000009010361353832042917,411e
5da500000009010304a42d3438c4e9,22
7b2800000009013834030445c76c42
5f92000000090103042d6239da0959,97
956500000009010304d82b39302db8,9e
073800000009010304b631306666a5,94
cc6d0000000901030446903963380d,e4
57960000006563090103045d644a1a
3b6c00000009010304d86438300785,87
8f4200000009010304c9307dbeea4f

1

tshark -r 工业控制协议流量分析2.pcap -T fields -Y '_ws.col.protocol == "TPKT"' -e tpkt.continuation_data > out.txt

1

tshark -r 工业控制协议流量分析2.pcap -T fields -Y '!(tpkt.continuation_data == 4d:4d:53:5f:50:41:59:4c:4f:41:44:5f:4e:4f:52:4d:41:4c)' -e tpkt.continuation_data > out.txt

1

tshark -r 工业控制协议流量分析2.pcap -T fields -Y '!(tcp.payload == 4d:4d:53:5f:50:41:59:4c:4f:41:44:5f:4e:4f:52:4d:41:4c)' -e tcp.payload > out.txt

1

tshark -r protocal.pcapng -T fields -Y 'mqtt' -e 'mqtt.msg' > out.txt

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12

'a': 440, 'b': 466, 'c': 494, 'd': 523, 'e': 554,
'f': 587, 'g': 622, 'h': 659, 'i': 698, 'j': 740,
'k': 784, 'l': 830, 'm': 880, 'n': 932, 'o': 988,
'p': 1047, 'q': 1109, 'r': 1175, 's': 1245, 't': 1319,
'u': 1397, 'v': 1480, 'w': 1568, 'x': 1661, 'y': 1760, 'z': 1865,
'1': 1000, '2': 2000, '3': 3000, '4': 4000, '5': 5000,
'6': 6000, '7': 7000, '8': 8000, '9': 9000, '0': 10000,
'A': 445, 'B': 471, 'C': 499, 'D': 528, 'E': 559,
'F': 592, 'G': 627, 'H': 664, 'I': 703, 'J': 745,
'K': 789, 'L': 835, 'M': 885, 'N': 937, 'O': 993,
'P': 1052, 'Q': 1114, 'R': 1180, 'S': 1250, 'T': 1324,
'U': 1402, 'V': 1485, 'W': 1573, 'X': 1666, 'Y': 1765, 'Z': 1870,

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98

import numpy as np
from scipy.io import wavfile

# 常量定义
DEFAULT_CHUNK_DURATION_MS = 100  # 默认分析块时长（毫秒）
FREQ_DIFF_THRESHOLD = 30         # 频率差异阈值
LOW_FREQ_THRESHOLD = 100         # 低频噪声阈值

# 频率与字符的对照表
FREQ_MAP = {
    # 小写字母
    'a': 440, 'b': 466, 'c': 494, 'd': 523, 'e': 554,
    'f': 587, 'g': 622, 'h': 659, 'i': 698, 'j': 740,
    'k': 784, 'l': 830, 'm': 880, 'n': 932, 'o': 988,
    'p': 1047, 'q': 1109, 'r': 1175, 's': 1245, 't': 1319,
    'u': 1397, 'v': 1480, 'w': 1568, 'x': 1661, 'y': 1760, 'z': 1865,

    # 数字
    '1': 1000, '2': 2000, '3': 3000, '4': 4000, '5': 5000,
    '6': 6000, '7': 7000, '8': 8000, '9': 9000, '0': 10000,

    # 大写字母（比对应小写字母稍高频率）
    'A': 445, 'B': 471, 'C': 499, 'D': 528, 'E': 559,
    'F': 592, 'G': 627, 'H': 664, 'I': 703, 'J': 745,
    'K': 789, 'L': 835, 'M': 885, 'N': 937, 'O': 993,
    'P': 1052, 'Q': 1114, 'R': 1180, 'S': 1250, 'T': 1324,
    'U': 1402, 'V': 1485, 'W': 1573, 'X': 1666, 'Y': 1765, 'Z': 1870,
}

def find_closest_char(target_freq):
    if not FREQ_MAP or target_freq < LOW_FREQ_THRESHOLD:
        return None

    # 找到最接近的频率对应的字符
    closest_char = min(FREQ_MAP.keys(),
                      key=lambda char: abs(FREQ_MAP[char] - target_freq))

    # 检查频率差异是否在可接受范围内
    if abs(FREQ_MAP[closest_char] - target_freq) > FREQ_DIFF_THRESHOLD:
        return None

    return closest_char


def analyze_wav_sequentially(file_path, chunk_duration_ms=DEFAULT_CHUNK_DURATION_MS):
    sample_rate, data = wavfile.read(file_path)
    # 如果是立体声，只使用左声道
    if data.ndim > 1:
        data = data[:, 0]

    # 计算每个块的大小（样本数）
    chunk_size = int(sample_rate * chunk_duration_ms / 1000)
    num_chunks = len(data) // chunk_size
    decoded_chars = []
    last_char = None

    print(f"[+] 采样率: {sample_rate} Hz, 块时长: {chunk_duration_ms} ms, 总块数: {num_chunks}")

    for i in range(num_chunks):
        start = i * chunk_size
        end = start + chunk_size
        chunk = data[start:end]

        # 对当前块进行 FFT 分析
        fft_spectrum = np.fft.rfft(chunk)
        fft_freq = np.fft.rfftfreq(len(chunk), 1.0 / sample_rate)

        # 找到主频率（忽略直流分量）
        if len(fft_spectrum) > 1:
            peak_index = np.argmax(np.abs(fft_spectrum[1:])) + 1
            dominant_frequency = fft_freq[peak_index]

            # 查找对应的字符
            char = find_closest_char(dominant_frequency)

            # 为了避免一个长音被重复记录，只有当字符变化时才记录
            if char and char != last_char:
                decoded_chars.append(char)
                last_char = char

    final_message = "".join(decoded_chars)

    print(f"[+] 解码出的字符序列: {final_message}")
    print(f"[+] 字符数量: {len(decoded_chars)}")
    return final_message


def func():
    wav_file = "video.wav"
    analyze_wav_sequentially(wav_file)


if __name__ == "__main__":
    func()

# [+] 采样率: 44100 Hz, 块时长: 100 ms, 总块数: 73
# [+] 解码出的字符序列: FvoelrnoBjmFz1aknoF7U24gFe5204521Be19B3voh9BSaqhGRlyXio6m0xtkEZ21nUmhelP
# [+] 字符数量: 72

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19

def hanio(n, a, b, c):
    res = ""
    if n == 1:
        res += f"{n}{a}{c}"
    else:
        # 将n-1个盘从a通过c移动到b
        res += hanio(n-1, a, c, b)
        # 将最大的盘从a移动到c
        res += f"{n}{a}{c}"
        # 将n-1个盘从b通过a移动到c
        res += hanio(n-1, b, a, c)
    return res

if __name__ == '__main__':
    n = 9
    result = hanio(n, 'A', 'B', 'C')
    print(result)

# 1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB5AC1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC6AB1CB2CA1BA3CB1AC2AB1CB4CA1BA2BC1AC3BA1CB2CA1BA5CB1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB7AC1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC5BA1CB2CA1BA3CB1AC2AB1CB4CA1BA2BC1AC3BA1CB2CA1BA6BC1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB5AC1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC8AB1CB2CA1BA3CB1AC2AB1CB4CA1BA2BC1AC3BA1CB2CA1BA5CB1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB6CA1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC5BA1CB2CA1BA3CB1AC2AB1CB4CA1BA2BC1AC3BA1CB2CA1BA7CB1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB5AC1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC6AB1CB2CA1BA3CB1AC2AB1CB4CA1BA2BC1AC3BA1CB2CA1BA5CB1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB9AC1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC5BA1CB2CA1BA3CB1AC2AB1CB4CA1BA2BC1AC3BA1CB2CA1BA6BC1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB5AC1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC7BA1CB2CA1BA3CB1AC2AB1CB4CA1BA2BC1AC3BA1CB2CA1BA5CB1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB6CA1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC5BA1CB2CA1BA3CB1AC2AB1CB4CA1BA2BC1AC3BA1CB2CA1BA8BC1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB5AC1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC6AB1CB2CA1BA3CB1AC2AB1CB4CA1BA2BC1AC3BA1CB2CA1BA5CB1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB7AC1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC5BA1CB2CA1BA3CB1AC2AB1CB4CA1BA2BC1AC3BA1CB2CA1BA6BC1AC2AB1CB3AC1BA2BC1AC4AB1CB2CA1BA3CB1AC2AB1CB5AC1BA2BC1AC3BA1CB2CA1BA4BC1AC2AB1CB3AC1BA2BC1AC

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

ADDRESS_ORDER
$ZIP_FILE_SCATTERED_ACROSS_FOUR_PARTS
WARNING: READ_RESPONSES_CONTAIN_INVALID_DATA
ZIP_PASSWORD_HINT
NOT_THE_DROID
ZIP_HINT_1
CHECK_DB2_AND_M
fl4g_k33p_
flag{zip_ascii_values_of_'flag'}
DATA_BEGIN_AT_ASCII_VALUES_OF_'f'
CAES_l_3:V0F3PP34
K_MAGIC_BYTE
looking_at_M_area}
READ_RESPONSES_ARE_INVALID_CHECK_WRITE_OPS
FOCUS_ON_S7_WRITE_VARIABLE_OPERATIONS
RED_HERRING
JUST_NOISE
HINT: PASSWORD_ENCRYPTED_WITH_CAESAR_SHIFT_3
FOCUS_ON_S7_WRITE_VARIABLE_OPERATIONS_ONLY
OT_IMPORTANT
flag{n0t_
ALL_DATA_FRAGMENTS_IN_M_AREA
PASSWORD_IN_DB_AREA_ADDRESS_0x60_WITH_CAESAR_CIPHER

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27

ADDRESS_ORDER
WARNING: READ_RESPONSES_CONTAIN_INVALID_DATA
READ_RESPONSES_ARE_INVALID_CHECK_WRITE_OPS
FOCUS_ON_S7_WRITE_VARIABLE_OPERATIONS
FOCUS_ON_S7_WRITE_VARIABLE_OPERATIONS_ONLY

ZIP_HINT_1
ZIP_FILE_SCATTERED_ACROSS_FOUR_PARTS

ZIP_PASSWORD_HINT
PASSWORD_IN_DB_AREA_ADDRESS_0x60_WITH_CAESAR_CIPHER
HINT: PASSWORD_ENCRYPTED_WITH_CAESAR_SHIFT_3

flag{n0t_fl4g_k33p_looking_at_M_area}
flag{zip_ascii_values_of_'flag'}

CAES_l_3:V0F3PP34

DATA_BEGIN_AT_ASCII_VALUES_OF_'f'
RED_HERRING
CHECK_DB2_AND_M
ALL_DATA_FRAGMENTS_IN_M_AREA
JUST_NOISE
OT_IMPORTANT
NOT_THE_DROID
K_MAGIC_BYTE
RED_HERRING

1

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

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20

def caesar_decrypt(data, shift=3):
    result = []
    for char in data:
        if char.isdigit():
            decrypted_digit = (int(char) - shift) % 10
            result.append(str(decrypted_digit))
        elif char.isalpha():
            if char.isupper():
                decrypted_char = chr((ord(char) - ord('A') - shift) % 26 + ord('A'))
            else:
                decrypted_char = chr((ord(char) - ord('a') - shift) % 26 + ord('a'))
            result.append(decrypted_char)
        else:
            # 其他字符保持不变
            result.append(char)
    return ''.join(result)

data  = "V0F3PP34"
print(caesar_decrypt(data))
# S7C0MM01

1
2

恭喜你找到了S7comm协议的秘密通道！
这是真正的flag: flag{S7c0mm_pr0t0col_st3g4n0graphy_mast3r}

1

tshark -r test.pcap -T fields -Y '(((ip.src == 192.168.1.200) || (ip.src == 192.168.1.201)) || (ip.src == 192.168.1.202)) && (modbus.func_code == 3)' -e 'tcp.payload' > out.txt

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15

with open('out.txt','r') as f:
    data = f.read().split()

# print(data)

res = ""
for item in data:
    if len(item) > 18:
        res += item[18:]

print(len(res))
print(bytes.fromhex(res))

with open("out.pdf",'wb') as f:
    f.write(bytes.fromhex(res))

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26

from string import ascii_lowercase, digits
import hashlib
from flag import flag

CHARSET = "!@#¥%" + ascii_lowercase + digits

n = len(CHARSET)
def encrypt(msg, f):
    chiper = ''
    for m in msg:
        chiper += CHARSET[f.substitute(CHARSET.index(m))]
    return chiper

P.<x> = PolynomialRing(GF(n))
f = P.random_element(6)


enc = encrypt(flag, f)
print("flag[0:7]", flag[0:7])
print("enc", enc)
print("hash", hashlib.sha256(flag.encode('utf-8')).hexdigest())


# flag[0:7] flkejiy
# enc quw7f59u51q¥##w¥w6q6s¥¥#w#661d¥
# hash 7d41757168a2199b32cb1744de130fdebda25271116bc64eccf4e397770d73c2

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144

from hashlib import sha256
from itertools import product
from multiprocessing import Pool, cpu_count
import math

CHARSET = "!@#¥%" + "abcdefghijklmnopqrstuvwxyz" + "0123456789"
p = len(CHARSET)  # 41

known_prefix = "flkejiy"  # flag[0:7]
enc = "quw7f59u51q¥##w¥w6q6s¥¥#w#661d¥"
target_hash = "7d41757168a2199b32cb1744de130fdebda25271116bc64eccf4e397770d73c2"

def inv_mod(a, p):
    a %= p
    if a == 0:
        raise ZeroDivisionError("no inverse")
    return pow(a, p-2, p)  # p prime

def lagrange_eval(t, xs, ys, p):
    total = 0
    k = len(xs)
    for i in range(k):
        xi, yi = xs[i], ys[i]
        num = 1
        den = 1
        for j in range(k):
            if j == i: continue
            xj = xs[j]
            num = (num * (t - xj)) % p
            den = (den * (xi - xj)) % p
        li = (num * inv_mod(den, p)) % p
        total = (total + yi * li) % p
    return total

def build_f_map(known_prefix, enc_prefix):
    xs = [CHARSET.index(ch) for ch in known_prefix]
    ys = [CHARSET.index(ch) for ch in enc_prefix]
    f_map = [lagrange_eval(i, xs, ys, p) for i in range(p)]
    return f_map

def build_candidates(enc, f_map):
    cand_list = []
    for c in enc:
        if c not in CHARSET:
            raise ValueError(f"cipher char {c!r} not in CHARSET")
        y = CHARSET.index(c)
        cands = [i for i, v in enumerate(f_map) if v == y]
        if len(cands) == 0:
            raise ValueError(f"No candidate for cipher char {c!r}")
        cand_list.append(cands)
    return cand_list

# single-worker search for product of candidates iterables
def search_chunk(prefix_indices, remaining_cands, target_hash):
    # prefix_indices: chosen indices for first k positions (list of ints)
    # remaining_cands: list of candidate-lists for positions k..end
    prefix = ''.join(CHARSET[i] for i in prefix_indices)
    # iterate remaining
    for tail in product(*remaining_cands):
        candidate = prefix + ''.join(CHARSET[i] for i in tail)
        if sha256(candidate.encode("utf-8")).hexdigest() == target_hash:
            return candidate
    return None

# helper for worker map: each worker gets a fixed prefix to extend
def worker_task(args):
    prefix_indices, remaining_cands, target_hash = args
    return search_chunk(prefix_indices, remaining_cands, target_hash)

def main():
    workers = cpu_count()
    print("CHARSET:", CHARSET)
    print("p:", p)
    print("known_prefix:", known_prefix)
    print("enc:", enc)
    print("target_hash:", target_hash)
    # build interpolation using known 7 pairs
    f_map = build_f_map(known_prefix, enc[:len(known_prefix)])
    cand_list = build_candidates(enc, f_map)
    counts = [len(c) for c in cand_list]
    total = 1
    for c in counts: total *= c
    print("candidate counts per position:", counts)
    print("total combinations:", total)

    # if small, brute force single-thread
    if total <= 5_000_000:
        print("Total combinations small: using single-thread brute force...")
        for combo in product(*cand_list):
            text = ''.join(CHARSET[i] for i in combo)
            if sha256(text.encode('utf-8')).hexdigest() == target_hash:
                print("Found flag:", text)
                return
        print("Not found.")
        return

    # otherwise use multiprocessing by splitting on first k positions
    # choose k so that number of prefixes ~= workers * ~2000 (tunable)

    target_prefix_count = workers * 2000
    k = 1
    prefix_space = len(cand_list[0])
    while prefix_space < target_prefix_count and k < len(cand_list):
        k += 1
        prefix_space *= len(cand_list[k-1])
    print(f"Splitting on first {k} positions -> prefix count {prefix_space}, using {workers} workers")

    # generate all prefixes (could be large but manageable for typical sizes)
    from itertools import product
    prefixes = list(product(*cand_list[:k]))
    remaining = cand_list[k:]

    # prepare tasks (each task: a fixed prefix)
    tasks = [(list(pref), remaining, target_hash) for pref in prefixes]

    print("Starting pool...")
    found = None
    with Pool(processes=workers) as pool:
        for res in pool.imap_unordered(worker_task, tasks, chunksize=1):
            if res:
                found = res
                pool.terminate()
                break

    if found:
        print("Found flag:", found)
        print("SHA256:", sha256(found.encode()).hexdigest())
    else:
        print("Not found (tried full parallel search).")

if __name__ == "__main__":
    main()

# CHARSET: !@#¥%abcdefghijklmnopqrstuvwxyz0123456789
# p: 41
# known_prefix: flkejiy
# enc: quw7f59u51q¥##w¥w6q6s¥¥#w#661d¥
# target_hash: 7d41757168a2199b32cb1744de130fdebda25271116bc64eccf4e397770d73c2
# candidate counts per position: [1, 1, 3, 2, 1, 4, 1, 1, 4, 1, 1, 2, 2, 2, 3, 2, 3, 2, 1, 2, 1, 2, 2, 2, 3, 2, 2, 2, 1, 4, 2]
# total combinations: 84934656
# Splitting on first 18 positions -> prefix count 27648, using 8 workers
# Starting pool...
# Found flag: flkejiyliafg77c3c4f49335c711avg
# SHA256: 7d41757168a2199b32cb1744de130fdebda25271116bc64eccf4e397770d73c2

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

import base64

with open("base64code.txt",'r') as f:

# print(len(data)) # 11

for idx,item in enumerate(data):
    png_name = f"{idx}.png"
    png_data = base64.b64decode(item)
    with open(png_name,'wb') as f:
        f.write(png_data)
    print(f"[+] {idx}.png 提取成功")
